Metric Welded Eye Bolt

Model: S0313-000x

Inexpensive and utilitarian, these metric eye bolts are very useful. Wire formed, 304 Stainless Steel.

See also: Unwelded Eye Bolts, Shoulder Eye Bolts, Heavy Duty Eye Bolts, and Welded Eye Bolts.


		Stainless Steel Facts See our All About Stainless Guide to learn about the materials from which these parts are made.



		Hardware Terms See our guide to hardware terminology. It'll help you sort out all the acronyms on our site.


		Suggested Tools These tools and materials are suggested for installation.

Metric Welded Eye Bolt 5mm x 2-1/4"	$1.81
Metric Welded Eye Bolt 5mm x 3-1/4"	$2.09
Metric Welded Eye Bolt 6mm x 1-1/2"	$2.47
Metric Welded Eye Bolt 6mm x 2-1/8"	$3.04
Metric Welded Eye Bolt 6mm x 3-1/8"	$3.33
Metric Welded Eye Bolt 8mm x 4"	$4.75
Metric Welded Eye Bolt 8mm x 3-1/8"	$4.28
Metric Welded Eye Bolt 10mm x 4"	7.70
Metric Welded Eye Bolt 10mm x 6"	8.55
Metric Welded Eye Bolt 12mm x 4"	9.41
Metric Welded Eye Bolt 12mm x 6"	13.68
In Stock - Usually ships in 1-2 business days.	Add to Cart

Learn More: Product Details | Accessories | Tools and Installation Materials

DIMENSIONS

Item Number	Size	A	B	C	D	E	WLL
S0313-0560	5mm x 2.25"	5mm	2.00"	2.25"	0.40"	Metric - 5mm	250
S0313-0580	5mm x 3.25"	5mm	3.00"	3.25"	0.40"	Metric - 5mm	250
S0313-0640	6mm x 1.5"	6mm	1.25"	1.50"	0.52"	Metric - 6mm	400
S0313-0660	6mm x 2.125"	6mm	2.00"	2.25"	0.52"	Metric - 6mm	400
S0313-0680	6mm x 3.125"	6mm	3.00"	3.25"	0.52"	Metric - 6mm	400
S0313-0810	8mm x 3.125"	8mm	3.00"	3.25"	0.65"	Metric - 8mm	600
S0313-0880	8mm x 4"	8mm	3.50"	4.00"	0.65"	Metric - 8mm	600
S0313-1010	10mm x 4"	10mm	3.50"	4.00"	0.77"	Metric - 10mm	1000
S0313-1015	10mm x 6"	10mm	5.50"	6.00"	0.93"	Metric - 10mm	1000
S0313-1210	12mm x 8"	12mm	3.50"	4.00"	1.02"	Metric - 12mm	1800
S0313-1215	12mm x 6"	12mm	4.00"	6.00"	1.02"	Metric - 12mm
